UL Listed as 2kV Heavy Duty Flexible Power Cable (HDFPC) DLO, Rated 90°C Dry or Wet.
DLO is a 2kV flexible power cable with a variety of possible applications such as but not limited to: Drilling rigs, railroad and transit car wiring, mining and other industrial equipment, and as flexible motor leads and wind turbine applications. The cable is suited for use in wet and dry areas, conduits, ducts, troughs, trays, and where superior electrical properties are desired. DLO is oil, heat, flame, abrasion, and sunlight resistant.
ICEA S-95-658/ NEMA WC-70: Nonshielded Power Cables Rated 2000 Volts or Less for the Distribution of Electrical Energy
UL Standard 44: Thermoset Insulated Wires & Cables, Types RHH, RHW-2. UL VW-1
UL Standard 1685: Vertical Tray Fire propagation and Smoke Release Test for Electrical and optical Fiber Cables. (UL, ST-1)
ASTM B-33: Standard Specification for Tinned Soft or Annealed Copper Wire for Electrical Purposes
ASTM B-172: Standard Specification for Rope-Lay-Stranded Copper
Size | Strands | Diameter Over Conductor | Insulation Thickness | Jacket Thickness | O.D. | Weight |
AWG/Kcmil | Nos | inch | mil | mil | inch | lbs/1000’ |
12 | 19 | 0.091 | 45 | 15 | 0.21 | 36 |
10 | 19 | 0.125 | 55 | 25 | 0.265 | 58 |
8 | 37 | 0.145 | 55 | 30 | 0.33 | 92 |
6 | 65 | 0.186 | 50 | 30 | 0.37 | 127 |
4 | 105 | 0.235 | 60 | 35 | 0.44 | 196 |
2 | 161 | 0.29 | 60 | 35 | 0.5 | 282 |
1 | 210 | 0.33 | 85 | 60 | 0.635 | 400 |
1/0 | 266 | 0.379 | 75 | 55 | 0.645 | 450 |
2/0 | 342 | 0.4 | 80 | 50 | 0.69 | 566 |
3/0 | 418 | 0.48 | 80 | 55 | 0.76 | 676 |
3/0 | 532 | 0.53 | 80 | 60 | 0.815 | 815 |
262.2 | 646 | 0.565 | 80 | 60 | 0.845 | 974 |
313.3 | 779 | 0.65 | 90 | 70 | 0.98 | 1139 |
373.7 | 931 | 0.701 | 95 | 70 | 1.04 | 1343 |
444.4 | 1121 | 0.782 | 90 | 65 | 1.105 | 1654 |
535.3 | 1330 | 0.843 | 105 | 75 | 1.212 | 1889 |
646.4 | 1628 | 0.89 | 115 | 80 | 1.29 | 2292 |
777.7 | 1924 | 0.966 | 120 | 90 | 1.405 | 2727 |
1111 | 2745 | 1.168 | 115 | 95 | 1.64 | 4161 |
