Aluminum Conductor PVC Insulated Steel Tape Armored PVC Sheathed Power Cable
(1)The highest allowed operating temperature of conductor for long-term working is 90 ° C.In short circuit (Max. Long term is no more than 5 seconds). The highest temperature for conductor is no more than 250 degrees.
(2)The environment temperature should be no lower than 0 when lay. Otherwise it should be preheated.
(3)The cable is laid without horizontal drop limit. The Min. Bending radius of three core cable should be no smaller than 12 times of cable outer diameter.
(4)Working Frequency Voltage Test:.For cable with Uo of 3.6kv~18kV: 3.5Uo/5min without puncture.
(5)Partial Discharge Test: The discharge volume should be no more than 10pC under 1.73Uo for the cable.
Conductor: Solid or stranded copper or aluminum
Insulation:PVC
Circuit Identification: The insulation shall be red, black
Filler:Polypropylene lament with lapped binding tape
Inner Sheath:Polyvinyl chloride (Black)
Core-covering:Binding tape
Outer Sheath:Polyvinyl chloride (Black)
Conductor: Solid or stranded copper or aluminum
Insulation:PVC
Circuit Identification: The insulation shall be red, black
Filler:Polypropylene lament with lapped binding tape
Inner Sheath:Polyvinyl chloride (Black)
Core-covering:Binding tape
Outer Sheath:Polyvinyl chloride (Black)
Nominal | at 20ºC,DC resistance is | Nominal | at 20ºC,DC resistance is | Nominal | at 20ºC,DC resistance is | |||
Copper Core | Aluminum Core | Copper Core | Aluminum Core | Copper Core | Aluminum Core | |||
1.5 | 12.1 | 18.1 | 35 | 0.524 | 0.868 | 240 | 0.0754 | 0.125 |
2.5 | 7.41 | 12.1 | 50 | 0.387 | 0.641 | 300 | 0.0601 | 0.100 |
4 | 4.61 | 7.41 | 70 | 0.268 | 0.443 | 400 | 0.0470 | 0.0778 |
6 | 3.08 | 4.61 | 95 | 0.193 | 0.320 | 500 | 0.0366 | 0.0605 |
10 | 1.83 | 3.08 | 120 | 0.153 | 0.253 | 630 | 0.0283 | 0.0469 |
16 | 1.15 | 1.91 | 150 | 0.124 | 0.206 | 800 | 0.0221 | 0.0369 |
25 | 0.727 | 1.20 | 185 | 0.0991 | 0.164 | 1000 | 0.0176 | 0.0291 |
Construction, Overhead, Underground, Industrial, Telecommunication, Computer
Q1.ABOUT US?
A1: Zhejiang Yuantong Wire & Cable Manufacturing Co., Ltd. is one of the enterprises of the high-end manufacturing sector of the Fortune Global 500 - Wuchan Zhongda Group(WZ Group) (stock code SH600704). It was Founded in 2000 with a registered capital of RMB 800 million, we are a leading technology company in China that produces the most complete varieties of Bare conductor & Power Cable & Fire-proof cable & UL & CSA List cables.
Q2：how about your quality?
A2: We have built a provincial "factory of the future" and have the largest single and most efficient special cable intelligent production workshop in Asia. There are advanced production equipment and skilled workers, as well as mature testing equipment.
Q3:how about your price?
A3: Due to our scale and high degree of automation, we can reduce labor costs and procurement costs, so our prices are very competitive in the cable industry
Q4:how about your delivery time?
A4: We have spare core, so our production time can be compressed to 7 days.If your order is large,please consult our sales staff for specific production time
Q5: can your offer sample service?
A5:we can provide free samples,but the shipping cost need be charged by you.
