Suitable for building and residential buildings,as sockets,switches and other load distribution;It can also be exposed to dry places to work,or concealed in dry or wet places.
Electric Wire | ||||
Cable type | Voltage class | Number of cores | Nominal cross-sectional area of conductor | Executive standard |
NMD90 | AC:300V | 2~4 2 | 14AWG~8AWG 14AWG~2AWG | CSAC22.2 No.48-15 |
AC90 | AC:600V、1000V | 2~4 | 14AWG~8AWG | CSAC22.2No.51-20 |
一、Range of application:
Suitable for building and residential buildings,as sockets,switches and other load distribution;It can also be exposed to dry places to work,or concealed in dry or wet places.Mainly used for residential wiring.Especially suitable for use as construction wire.
二、Product feature:
It has excellent thermal stability,mechanical strength,cold resistance,surface hardness,bending strength, impact strength,wear resistance,chemical resistance,oil resistance,gasoline resistance and self-lubrication,and adopts nylon protective layer to make the appearance bright and easy to be laid through the pipe.
