Compact stranded BC conductor;medium voltage cable;steel tape cable;3 cores copper conductor cable;
1.Long term working temperature is up to 90 degree C.
2.The highest conductor temperature is not more than 250 degree C.(lasting time not over 5 seconds.)
3.Laying temperature not less than 0 degree C and the drop height is out of consideration.
4.The cable with chemical stability, anti acid, anti alkali, and oil, anti organic solvent, not easy to be burning,easy for installation, easy beading and light.
(1)Conductor:compact BC conductor
(2)Insulation:XLPE
(3)Screen:copper tape screen
(4)Sheathe:overall LOSH sheathe
(5)standard:IEC 6050,IEC60332 or IEC60331
(6)products parameter:
Normal area | Conductor Construction | Outside Diameter | Sheath Thickness |
1.5 | 7/0.52 | 6 | 1.5 |
2.5 | 7/0.67 | 6 | 1.5 |
4 | 7/0.84 | 7 | 1.5 |
6 | 7/1.04 | 7 | 1.5 |
10 | 7/1.35 | 8 | 1.5 |
16 | 7/1.7 | 9 | 1.5 |
25 | 7/2.14 | 10 | 1.5 |
35 | 7/2.52 | 12 | 1.5 |
50 | 19/1.78 | 13 | 1.5 |
70 | 19/2.14 | 14 | 1.5 |
95 | 19/2.52 | 16 | 1.5 |
120 | 37/2.03 | 18 | 1.5 |
150 | 37/2.25 | 21 | 2 |
185 | 37/2.52 | 23 | 2 |
240 | 61/2.25 | 25 | 2 |
3x1.5 | 3x7/0.52 | 10 | 1.5 |
3x2.5 | 3x7/0.67 | 11 | 1.5 |
3x4.0 | 3x7/0.84 | 12 | 1.5 |
3x6.0 | 3x7/1.04 | 13 | 1.5 |
3x10.0 | 3x7/1.35 | 15 | 1.5 |
3x16 | 3x7/1.7 | 17 | 2 |
3x25 | 3x7/2.14 | 21 | 2 |
3x35 | 3x7/2.52 | 23 | 2 |
3x50 | 3x19/1.78 | 27 | 2 |
3x70 | 3x19/2.14 | 30 | 2.5 |
3x95 | 3x19/2.52 | 34 | 2.5 |
3x120 | 3x37/2.03 | 38 | 2.5 |
3x150 | 3x37/2.25 | 42 | 2.5 |
3x185 | 3x37/2.52 | 45 | 2.5 |
3x240 | 3x61/2.25 | 51 | 3 |
Fixed laying, can be used for indoor exposed laying or pipe threading and other occasions
